1710 driveshaft
Details:
Product features, advantages, and benefits include:
High-angle yokes allow for up to 45 degree angles.
Thick wall DOM tubing (4.095 X .180) for enhanced strength and durability.
Improves customer satisfaction by minimizing downtime in the shop. No need to wait for the shaft to be built.
Maximizes service bay efficiency thus maximizing shop revenue and profits.
Optimizes driveshaft shop efficiencies. Less time spent on small shafts, more time spent on big shafts.
|
ADDITIONAL DETAILS |
|||
|
1 |
DS1710IA-1722HR |
1710 |
Allows for 5.5" travel 17.22" collapsed length to 22.72" extended length |
|
1 |
DS1710IA-1825HR |
1710 |
Allows for 5.5" travel 18.25" collapsed length to 23.75" extended length |
|
2 |
DS1710IA-2028HR |
1710 |
Allows for 5.0" travel 20.28" collapsed length to 25.28" extended length Includes 2.5" of 4.095" x .180 tube welded to stub shaft and weld yoke |
|
2 |
DS1710IA-2200HR |
1710 |
Allows for 5.0" travel 22.00" collapsed length to 27.00" extended length Includes 4.25" of 4.095" x .180 tube welded to stub shaft and weld yoke |
|
2 |
DS1710IA-2400HR |
1710 |
Allows for 5.0" travel 24.00" collapsed length to 29.00" extended length Includes 6.25" of 4.095" x .180 tube welded to stub shaft and weld yoke |
